Rated voltage: AC 100 V ~ 240 V 50/60 Hz

Power: 400W

Lamp bead: LED module

Rated life: 20,000 hours,

Color temperature: 7500K

Beam angle: zoom 0°～ 5°160mm large aperture light,

Color wheel: a color wheel, which consists of 13 color films+blanks;

Pattern disk: a pattern disk, which consists of 13 patterns+blanks;

Prism: 2 rotatable prisms: a 16 prism and an 8 prism; Prisms can overlap, three prism effects;

Atomization: an atomizing mirror or a colorful mirror is optional;

Optical angle: parallel beam angle 0 ~ 2.0, atomizing light angle 8;

Light exit aperture: 160mm,

Lens: multi-group high-precision lens combination, advanced optical design, maximum efficiency use of light source, brighter and fuller beam;

Dimming: 0-100% mechanical dimming;

Focus: linear focus;

Strobe: electronic strobe, 0.3 ~ 25 times/second, synchronous and asynchronous random strobe can be selected;

Horizontal scanning: 540 (16 bit precision scanning) electronic error correction;

Vertical scanning: 270 (16-bit precision scanning) electronic error correction;

Cooling system: built-in cooling mute fan forced air cooling, electronic temperature control overheating protection;

Fuselage material: high temperature resistant plastic+molded alloy material;

Connection mode: 3-core Calon DMX input and output, power input;

Working environment: indoor-20 ~ 40℃;

IP protection level: IP20.

Dimensions: total length 590.5, bottom length 372.56 and width 265 mm.
